ISM Band Antenna φ19×32.5 mm
2.4 GHz
ISM
2.4 GHz ISM band antenna for Wi-Fi, Bluetooth, and Zigbee applications. φ19×32.5 mm with Linear polarisation.
Every novocomms antenna is characterised in our in-house anechoic chamber. Radiation patterns, total efficiency, and return loss are fully measured across the specified operating bands. The performance you see in the datasheet is the performance you can rely on in your design.
Key Specifications
| Dimensions | φ19×32.5 mm |
| Frequency | 2.4-2.483 GHz |
| Return Loss | ≥10 dB |
| Gain | 1.5 dBi |
| Ground Plane | φ30 mm |
| Polarisation | Linear |
| Impedance | 50Ω |
Typical values shown. Final integration performance depends on host device layout, enclosure, and installation environment.
