ISM Band Antenna φ46×15 mm

2.4 GHz ISM

2.4 GHz ISM band antenna for Wi-Fi, Bluetooth, and Zigbee applications. φ46×15 mm with RHCP polarisation.

View Specifications Request Datasheet

Every novocomms antenna is characterised in our in-house anechoic chamber. Radiation patterns, total efficiency, and return loss are fully measured across the specified operating bands. The performance you see in the datasheet is the performance you can rely on in your design.

Key Specifications

Dimensions φ46×15 mm
Frequency 2.4-2.483 GHz
Return Loss ≥10 dB
Gain 4.5 dBic
Ground Plane φ50 mm
Polarisation RHCP
Impedance 50Ω

Typical values shown. Final integration performance depends on host device layout, enclosure, and installation environment.
